RENDER - RabbitEars NextGen Data Evaluator Report - v0.2.1

• Global Service ID: tag:sinclairplatform.com,2021:WIAV:9101
• Category: 1 (Linear A/V Service)
• SLS Destination: 239.255.58.1:5001
• SLS Source: 10.252.36.2
• SLS Protocol Version: 0.0 (ROUTE)

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5001"><DeliveryMethod><BroadcastAppService><BasePattern>a0-a02_2-</BasePattern><BasePattern>d3_3-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

ROUTE Stream: :

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="2000000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-14 D-L',{0 'TV-14'}{1 'D'}{2 'L'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-a02_2-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a0-a02_2-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a02_2"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d3_3-$TOI$.m4s"><fdt:File TOI="1" Content-Location="d3_3-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="d3_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="54"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="229"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="66"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="5"></item></metadataEnvelope>

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

• Bandwidth: 2000000 (2.0 Mbps)
• Codecs: hev1.2.4.L120.B0
• Resolution: 1920x1080 (16:9)
• Frame Rate: 30000/1001 (29.97 fps)
• Scan Type: progressive
• Sample Aspect Ratio: 1:1
• Segment Template:
  • Initialization: video-init.mp4
  • Media URL: video-$Number$.mp4v
  • Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

• Bandwidth: 96000 (96 kbps)
• Codecs: ac-4.02.01.00
• Audio Sample Rate: 48000 Hz
• Audio Channels: 2
• Segment Template:
  • Initialization: a0-$RepresentationID$-init.mp4
  • Media URL: a0-$RepresentationID$-$Number$.m4s
  • Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: d3_3

• Bandwidth: 50000 (50 kbps)
• Codecs: stpp.ttml.im1t
• Segment Template:
  • Initialization: $RepresentationID$-init.mp4
  • Media URL: $RepresentationID$-$Number$.m4s
  • Timescale: 240000, Duration: 240240, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT1.001S" minBufferTime="PT1S" minimumUpdatePeriod="PT10S" profiles="urn:mpeg:dash:profile:isoff-live:2011" publishTime="2025-10-31T00:10:32Z" timeShiftBufferDepth="PT6S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="30000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="30000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14 D-L',{0 'TV-14'}{1 'D'}{2 'L'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>               <Representation bandwidth="2000000" codecs="hev1.2.4.L120.B0" frameRate="30000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920">            <SegmentTemplate duration="240240" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>         </Representation></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14 D-L',{0 'TV-14'}{1 'D'}{2 'L'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.00" id="a02_2">            <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>            <SegmentTemplate duration="240240" initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         </Representation></AdaptationSet><AdaptationSet contentType="text" id="2" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14 D-L',{0 'TV-14'}{1 'D'}{2 'L'}"/>         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="subtitle"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="d3_3">            <SegmentTemplate duration="240240" initialization="$RepresentationID$-init.mp4" media="$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         </Representation></AdaptationSet>   </Period></MPD>

• Broadband Entry Page: https://d3o3enj75dempy.cloudfront.net/run3tv-common/index.html

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage bbandEntryPageUrl="https://d3o3enj75dempy.cloudfront.net/run3tv-common/index.html"   appContextId="tag:sinclairplatform.com,2021:WIAV:9101" ></HTMLEntryPackage>
</HELD>

• Global Service ID:
• Category: 4 (ESG Service)
• SLS Destination: 239.255.58.1:5100
• SLS Source: 10.252.36.2
• SLS Protocol Version: 0.0 (ROUTE)

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5002"></UserServiceDescription></BundleDescriptionROUTE>

ROUTE Stream: 239.255.58.1:5100

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS sIpAddr="10.252.36.2" dIpAddr="239.255.58.1" dPort="5100"><LS tsi="50"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="1833" Content-Location="sgdd_1833" Content-Length="13178" Transfer-Length="1426" Content-Type="application/vnd.oma.bcast.sgdd+xml" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="60"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="3977" Content-Location="sgdu_content_3977" Content-Length="100454" Transfer-Length="7158" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File><fdt:File TOI="4904" Content-Location="sgdu_service_schedule_4904" Content-Length="17345" Transfer-Length="1939" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="80"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="5190" Content-Location="s102116_ll_h15_ac.png" Content-Length="9117" Transfer-Length="8676" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="11"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="806"></item></metadataEnvelope>

• Global Service ID: tag:broadspanwireless.com,2023:9100:WIAV-CD:9101
• Category: 3 (App-Based Service)
• SLS Destination: 239.255.58.100:6000
• SLS Source: 10.252.36.2
• SLS Protocol Version: . (ROUTE)
• Hidden: Yes
• Hide in Guide: Yes

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="dwd.dwd" contentType="application/atsc-dwd+xml" version="1"></item></metadataEnvelope>

Raw XML

<?xml version="1.0" encoding="UTF-8"?><DWD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/DWD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/DWD/1.0/ DWD-1.0-20180830.xsd"><DistributionWindow startTime="2025-10-28T15:54:11Z" endTime="2025-10-28T15:57:35Z" lctTSIRef="1000" contentLabel="2"><AppContextId dwFilterCode="234232">base:context:id</AppContextId></DistributionWindow></DWD>

BroadSpan Service: DDAAS

• Reservation Name: RTK
• Service ID in UDST: 5004
• Destination: 239.255.58.103:6123
• Order ID: 2025-08-20-RTK-Route-4

Raw XML

<?xml version="1.0" encoding="UTF-8"?>
<UDST version="0.1">
    <UDS>
        <broadSpanServices>
            <broadSpanService name="DDAAS">
                <rsrv apiKey="" callbackUrl="" destIP="239.255.58.103" destPort="6123" mktid="" name="RTK" orderId="2025-08-20-RTK-Route-4" srvid="5004"/>
            </broadSpanService>
        </broadSpanServices>
    </UDS>
</UDST>

• Global Service ID: tag:sinclairplatform.com,2020,247MMT:9109
• Category: 1 (Linear A/V Service)
• SLS Destination: 239.255.58.5:5006
• SLS Source: 10.252.36.2
• SLS Protocol Version: 0.0 (MMT)

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionMMT xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/MMTUSD/1.0/" xmlns:sa="tag:atsc.org,2016:XMLSchemas/ATSC3/SA/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/MMTUSD/1.0/ MMTUSD-1.0-20210401.xsd"><UserServiceDescription serviceId="5006"><Channel serviceIcon="service_icon"><ServiceDescription serviceDescrText="TBD" serviceDescrLang="en"></ServiceDescription></Channel><MPUComponent mmtPackageId="mmt"></MPUComponent><ComponentInfo componentType="1" componentRole="0" componentProtectedFlag="false" componentId="videoasset01"></ComponentInfo><ComponentInfo componentType="0" componentRole="0" componentProtectedFlag="false" componentId="audioasset02"></ComponentInfo><ComponentInfo componentType="2" componentRole="0" componentProtectedFlag="false" componentId="subtitleasset03"></ComponentInfo></UserServiceDescription></BundleDescriptionMMT>

Components:

Raw XML

<?xml version="1.0" encoding="UTF-8"?><UserServiceDescription serviceId="5006">
  <Channel serviceIcon="service_icon">
    <ServiceDescription serviceDescrText="TBD" serviceDescrLang="en"/>
  </Channel>
  <MPUComponent mmtPackageId="mmt"/>
  <ComponentInfo componentType="1" componentRole="0" componentProtectedFlag="false" componentId="videoasset01"/>
  <ComponentInfo componentType="0" componentRole="0" componentProtectedFlag="false" componentId="audioasset02"/>
  <ComponentInfo componentType="2" componentRole="0" componentProtectedFlag="false" componentId="subtitleasset03"/>
</UserServiceDescription>

Binary MMT Package Table

Video Stream Properties Descriptor (VSPD)

• Codec: hev1.2.2.L123.B (HEVC/H.265)
• HEVC Profile: Main 10 (supports 10-bit color depth for HDR content)
• HEVC Level: 4.1 (defines maximum resolution, frame rate, and bitrate capabilities)
• Tier: Main (Main tier: standard bitrates, High tier: allows higher bitrates)
• Scan Type: Progressive (full frames, better quality)

Audio Stream Properties Descriptor (ASPD)

• Codec: ac-4 (Dolby AC-4 - next-generation audio codec)
• Language: en
• Presentations: 1 (separate audio mixes, e.g., main, commentary, descriptive)
• Sample Rate: 48000 Hz

Caption Asset Descriptor (CAD)

• Caption Track 1:
  • Language: en
  • Role: main (primary captions)
  • Aspect Ratio: 16:9
  • Profile: text (text-based captions)
