RENDER - RabbitEars NextGen Data Evaluator Report - v0.2.1

Physical Layer Pipes - 2 PLPs (L1 BSID: Not Set)

PLP ID	SFI	Modulation	Code Rate	Layer	TI Mode	LLS	Lock	Required SNR	Bitrate
0	0	16QAM	9/15	core	hti	Yes	Yes	AWGN: 7.32 dB Rayleigh: 9.94 dB	0.622 Mbps
1	0	256QAM	9/15	core	hti	Yes	Yes	AWGN: 15.55 dB Rayleigh: 18.23 dB	24.871 Mbps

L1 Signaling Details (From L1Detail)

--- L1-Basic Signaling ---

L1B_version: 0

L1B_mimo_scattered_pilot_encoding: Walsh-Hadamard

L1B_lls_flag: LLS present

L1B_time_info_flag: ns precision

L1B_return_channel_flag: 0

L1B_papr_reduction: None

L1B_frame_length_mode: Symbol-aligned

  L1B_time_offset: 3840

  L1B_additional_samples: 0

L1B_num_subframes: 1

L1B_preamble_num_symbols: 1

L1B_preamble_reduced_carriers: 0

L1B_L1_Detail_content_tag: 0

L1B_L1_Detail_size_bytes: 42

L1B_L1_Detail_fec_type: Mode 1

L1B_L1_additional_parity_mode: K=0

L1B_L1_Detail_total_cells: 3611

L1B_first_sub_mimo: No MIMO

L1B_first_sub_miso: 0

L1B_first_sub_fft_size: 16K

L1B_first_sub_reduced_carriers: 0

L1B_first_sub_guard_interval: GI_3_512

L1B_first_sub_num_ofdm_symbols: 100

L1B_first_sub_scattered_pilot_pattern: 13

L1B_first_sub_scattered_pilot_boost: 0

L1B_first_sub_sbs_first: 1

L1B_first_sub_sbs_last: 1

L1B_crc: 0x00000000

--- L1-Detail Signaling ---

L1D_version: 0

L1D_num_rf: 0

L1D_time_sec: 1767470740

L1D_time_msec: 273

L1D_time_usec: 24

L1D_time_nsec: 220

Subframe #0:

  L1D_frequency_interleaver: All Symbols

  L1D_sbs_null_cells: 0

  L1D_num_plp: 2

    PLP #0:

      L1D_plp_id: 0

      L1D_plp_lls_flag: 1

      L1D_plp_layer: Core

      L1D_plp_start: 0

      L1D_plp_size: 64800

      L1D_plp_scrambler_type: PRBS

      L1D_plp_fec_type: BCH + 64K LDPC

      L1D_plp_mod: 16QAM

      L1D_plp_cod: 9/15

      L1D_plp_TI_mode: HTI

      L1D_plp_type: non-dispersed

      L1D_plp_HTI_inter_subframe: 0

      L1D_plp_HTI_num_ti_blocks: 1

      L1D_plp_HTI_num_fec_blocks_max: 4

      L1D_plp_HTI_num_fec_blocks: 4

      L1D_plp_HTI_cell_interleaver: 0

      -> PLP Bitrate: 0.622 Mbps

    PLP #1:

      L1D_plp_id: 1

      L1D_plp_lls_flag: 1

      L1D_plp_layer: Core

      L1D_plp_start: 64800

      L1D_plp_size: 1296000

      L1D_plp_scrambler_type: PRBS

      L1D_plp_fec_type: BCH + 64K LDPC

      L1D_plp_mod: 256QAM

      L1D_plp_cod: 9/15

      L1D_plp_TI_mode: HTI

      L1D_plp_type: non-dispersed

      L1D_plp_HTI_inter_subframe: 0

      L1D_plp_HTI_num_ti_blocks: 10

      L1D_plp_HTI_num_fec_blocks_max: 160

      L1D_plp_HTI_num_fec_blocks: 160

      L1D_plp_HTI_cell_interleaver: 0

      -> PLP Bitrate: 24.871 Mbps

L1D_crc: 0xffffffffbdeeaf74

Link Mapping Table (LMT) Version 0 - 11 Service(s)

PLP ID	Source IP:Port	Destination IP:Port	Service ID	Service Name	Flags
0	0.0.0.0:0	239.255.14.100:6000	5008	DDAAS	None
1	0.0.0.0:0	239.255.14.1:5000	5001	KFOX	None
1	0.0.0.0:0	239.255.14.1:5100	5002	ESG	None
1	0.0.0.0:0	239.255.4.1:5000	5003	KDBC	None
1	0.0.0.0:0	239.255.9.1:5000	5004	KTSM	None
1	0.0.0.0:0	239.255.48.1:5000	5005	KTDO	None
1	0.0.0.0:0	239.255.7.1:5000	5006	KVIA	None
1	0.0.0.0:0	239.255.14.10:5000	5007	T2	None
1	0.0.0.0:0	239.255.14.11:5000	5009	PBTV	None
1	0.0.0.0:0	239.255.14.20:5000	5010	GMLOOP	None
1	0.0.0.0:0	239.255.14.21:5000	5011	ROXi	None

Service Summary (SLT BSID: 2828)

Service Name	ID	Channel	PLP	Protocol / Category	SLS Destination
KFOX	5001	14.1	1	ROUTE / Linear A/V Service	239.255.14.1:5000
ESG	5002		1	ROUTE / ESG Service	239.255.14.1:5100
KDBC	5003	4.1	1	ROUTE / Linear A/V Service	239.255.4.1:5000
KTSM	5004	9.1	1	ROUTE / Linear A/V Service	239.255.9.1:5000
KTDO	5005	48.1	1	ROUTE / Linear A/V Service	239.255.48.1:5000
KVIA	5006	7.1	1	ROUTE / Linear A/V Service	239.255.7.1:5000
T2	5007	14.10	1	ROUTE / Linear A/V Service	239.255.14.10:5000
DDAAS	5008		0	ROUTE / App-Based Service	239.255.14.100:6000
PBTV	5009	14.11	1	ROUTE / Linear A/V Service	239.255.14.11:5000
GMLOOP	5010	14.20	1	ROUTE / App-Based Service	239.255.14.20:5000
ROXi	5011	14.21	1	ROUTE / App-Based Service	239.255.14.21:5000

Capability Descriptor Table (CDT) - 3 Certificate(s)

Attribute	Value
OCSP Refresh	P7DT0H
Certificate Count	3

Certificate Details

Certificate 1 - ATSC 3.0 Signing CA-2 (Valid Until: Sep 8 2030)

Field	Value
Subject	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Issuer	/C=US/O=Pearl TV/OU=Root CA-1/CN=ATSC3 Root-CA
Serial Number	1D81C0A269A03D9AAF128428593DB6B8
Valid From	Sep 8 00:00:00 2021 GMT
Valid Until	Sep 8 23:59:59 2030 GMT
Signature Algorithm	sha512WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	06:63:9A:0C:E9:C0:E7:2C:44:05:1C:8A:91:B6:68:FB:25:C4:38:75
SHA-256 Fingerprint	23:42:5B:1C:CA:CB:F3:31:7C:8B:03:59:DA:E0:A3:98:C4:84:05:DB:1B:6B:92:15:58:69:F7:89:30:9A:65:
Certificate Authority	Yes
Self-Signed	No

Certificate 2 - KFOX-TV Signalling Signing SMT 0001 (Valid Until: Sep 16 2026)

Field	Value
Subject	/C=US/ST=Texas/L=El Paso/O=Sinclair Broadcast Group, Inc./OU=Sinclair Broadcast Group, Inc/CN=KFOX-TV Signalling Signing SMT 0001
Issuer	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number	611B51DE567EE0A22DDB35983FF20333E9A72DFB
Valid From	Sep 16 18:52:23 2025 GMT
Valid Until	Sep 16 18:52:23 2026 GMT
Signature Algorithm	sha256WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	8E:DA:15:C7:70:16:E9:F6:61:C3:B6:C7:3A:21:2D:E9:DA:63:1D:29
SHA-256 Fingerprint	7B:33:08:11:88:81:20:A4:E7:5A:66:0B:B4:3C:0B:6A:42:30:16:89:95:29:72:FF:8A:6F:1B:8C:80:DF:08:
Certificate Authority	No
Self-Signed	No

Certificate 3 - KFOX-TV Signalling Signing CDT 0001 (Valid Until: Sep 16 2026)

Field	Value
Subject	/C=US/ST=Texas/L=El Paso/O=Sinclair Broadcast Group, Inc./OU=Sinclair Broadcast Group, Inc/CN=KFOX-TV Signalling Signing CDT 0001
Issuer	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number	4EA874006C6AE575C81CC266C6812362B2CA6C41
Valid From	Sep 16 18:52:22 2025 GMT
Valid Until	Sep 16 18:52:22 2026 GMT
Signature Algorithm	sha256WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	5E:98:9D:B6:26:55:E0:67:2A:32:54:44:54:B6:BB:0E:A5:0C:16:06
SHA-256 Fingerprint	EF:BF:B3:1D:BB:A8:DD:80:39:A0:53:14:26:93:26:11:B1:3D:91:F3:0D:A7:91:CB:DB:77:D4:33:88:76:39:
Certificate Authority	No
Self-Signed	No

Raw XML

<?xml version="1.0" encoding="UTF-8"?>
<CertificationData xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/CDT/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/CDT/1.0/CDT-1.0-20180706.xsd">
<ToBeSignedData OCSPRefresh="P7DT0H"><Certificates>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</Certificates><Certificates>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</Certificates><Certificates>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</Certificates><CurrentCert>23xAM7oJWmSLDqsDC5qQqNZ/N9I=</CurrentCert></ToBeSignedData>
<CMSSignedData>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</CMSSignedData>
<OCSPResponse>MIIIsgoBAKCCCKswgginBgkrBgEFBQcwAQEEggiYMIIIlDCBnqIWBBQlGyMonliwHKjHqZYM3G5k9QwEFxgPMjAyNjAxMDExODIyMDZaMHMwcTBJMAkGBSsOAwIaBQAEFM+Hj12/7wjLRzG4kQv8vkI0u9TWBBQFacL8uojw4Bz4cnFYALieCoBxpgIQHYHAommgPZqvEoQoWT22uIAAGA8yMDI2MDEwMTE4MjIwNlqgERgPMjAyNjAxMDgxODIyMDZaMA0GCSqGSIb3DQEBCwUAA4ICAQCXXy60wQQc68vRJDzoIclzpOILo90WThNwnht9kNEiqmFCuFdrs2Pd9slXZhiXGeWpB17ktVwxAKWz3Xoikxa0t90gglqUHX1K0NWGzdAcK0XDsYdvQPjJVA4sJ58UzySjSr8iYmcWufPpIZubR4tXxjfyxPkkrYySrh22imEEzy7gHAnobG/v06c2eit/M9TLSSNTCe/3V37TMdHSPy7EiqGtvfT0T85kMGuv/AwWI/D0ONRiy/gGNDxHfUmmKhBN3CQBnqc88IJ9q1zlcUFBIjYRglcH2HKoT/fWqW3YB7+JNEoftLqDMFfrBrk+OXcGLUcP+I5Na+ccV6phCyoUJh58JESIhmMBF8OONCK00tMLCtHHDIcUhIMWzil27INMZJhSB5/cSfp1VvwPC0YXqDiStOt1N+3z7HAMjlo78vf7sI55A34kb7hiJ1FlebotDTew1ZOg48ptmlrqxTZCDYDyv0jQ00Uajm18YklKgUPHjW+rEBuv1ZUKBKKjt+TzPuvHUiVDcWbWoSPjk0F3RcOGIjFJ0m+/w9GU2LyCGV5kUtE74Z+OhszpcgyQ/ZutOYWcBxeUGmkfDlFpSrASS8/rG6G5VnhyNwCxyGbCIAmvEDkSH4jxBYHsqxXGU+WEehrXHhigRJlM1Ejb5r1FNcMruQ8oNBkduFfz1lUcUqCCBdswggXXMIIF0zCCA7ugAwIBAgIQHMX0ZUcKBuKgYs03+pW++TANBgkqhkiG9w0BAQsFADBMMQswCQYDVQQGEwJVUzERMA8GA1UEChMIUGVhcmwgVFYxEjAQBgNVBAsTCVJvb3QgQ0EtMTEWMBQGA1UEAxMNQVRTQzMgUm9vdC1DQTAeFw0yMTA0MTQwMDAwMDBaFw0yNjA0MTMyMzU5NTlaMF0xCzAJBgNVBAYTAlVTMREwDwYDVQQKEwhQZWFybCBUVjESMBAGA1UECxMJUm9vdCBDQS0xMScwJQYDVQQDEx5BVFNDMyBSb290LUNBIE9DU1AgUmVzcG9uZGVyIDMwggIiMA0GCSqGSIb3DQEBAQUAA4ICDwAwggIKAoICAQDEmI+HliOvphPufaSpUoAxniQrf3iCrjaycSZ+tQgJlk0ZSux0r/K3GysVt+ZA11RqocX/23sgXfvxjNokhf4ssoADnJ+vv2ghbrmKoGK4NDUwAHw5n9KHZJM4Q6PGhwFm0qaC87zya2Fkks0PwGb/XMlzvd3dGjVpLVDrKQEKdLO9xgv8UE8EH/SfgMoi472BjPmN+lysFD0LkRiepGlP+nJBwklnq+eV7sMaBAMpx1CCcIT3cJx6tEEs4l+MWTQgArzLdyD7z0uFBxvaE6wK/FWx72Ep9fgLnonK/QRfev9z3Fwg8Z+XCbvVpP1DpeaLbmlzY46RHTIX7c31TCIjiCv1IpFg9O0b0ANyQ6xcWgH8fefY9Jylud/U73NivGy/XZXBRatlUf5CEXM54oZ2QNayKD6O4XlGGdmzxy4vz5cpNeaiSu65rUIBsxSBPTuWh9ZkDz5h0sOH4LNvfYrwV9+din0KqPoLyveuE9L8MTtqSN32SqkxAfzoNduL0hd/7TbgRGnNtliJMnLIWQzMcvWGHfKjGrmicNlJfvNE5L/Mkd+1ApOA4AsyQaToLBjB2mrJAvwDmd2s7ILO9mcF582WTgNvrjkEF1RUWtLXBGtaKgJlrc5CECMTIT9r+8hqF33IxSkVbyonMctuypi2z9whsB7b9vDlKBvFagC6hQIDAQABo4GfMIGcMAwGA1UdEwEB/wQCMAAwEwYDVR0lBAwwCgYIKwYBBQUHAwkwDgYDVR0PAQH/BAQDAgeAMA8GCSsGAQUFBzABBQQCBQAwFgYDVR0gBA8wDTALBgkrBgEEAYOUYwEwHQYDVR0OBBYEFCUbIyieWLAcqMeplgzcbmT1DAQXMB8GA1UdIwQYMBaAFAVpwvy6iPDgHPhycVgAuJ4KgHGmMA0GCSqGSIb3DQEBCwUAA4ICAQCRIOGMBfBBOuqVI+yc4iM5DcggxHyyQ7rOWUXefj+reCeofLldvaAUDdBhLoJFzBUPyY6hW0Sf9y3H9zQ/xkNZzuthE66hQ+ss9HsJWargjIqlLSc8AtSyeljcXvF7Ht1dEsQIWOh+rFmGWtvb3pjyVSf5Xhuox/4+MplJ1NcpI6SbbvWk0bSobRgaZfBXpwWCJOFOpBhxsKuQZp3GqeiBr7KaYVwKtKsrctMupYjm6Y2LPl8IPB3zMKFceRQKOAfQfWAcgTVkmDQeTYv910ris8YaX7kPotViuz/erJSTAhrcCx1OLdx3AHFch+QwRXAH+xwYE0Z0qQH95qduqgdUvOL74m90Nu3X88vy4mpyBnAhaZYimJlcPH7Ce1JBtIEX1T9Fhm6HPTj5BIkTRt+s/FQwrPlMjepm5aZbX1A4tDbcPDKyXdvmIIoGKxqbXkE47W4zlgr+YIVA5qIHwPtrE1OUy1n+NNPpXbLVS2AtW1fwLRbgkQtjT/Pu9ZQaB1RgrVpg9w9W1fY8C3vJvTPTVlUVy+MoAkXqXYWXEYxLMWzB0/AzO758LExkRNEl9ko53e5r91vnXPpPmrYSrNSXAXbTL6qVvuQmNvlPW+VmjrozI6TF5IkeLarjo9A9zfxVqGbiAXX/rVeiJr3gEyteGTYPCYEbUxhHeVPRR3xpww==</OCSPResponse><OCSPResponse>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</OCSPResponse><OCSPResponse>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</OCSPResponse>
</CertificationData>

Service List Table (SLT) Instance 1 - Raw XML

<?xml version="1.0" encoding="UTF-8"?>
<SLT bsid="2828" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SLT/1.0/ SLT-1.0-20211209.xsd">
    <Service globalServiceID="tag:sinclairplatform.com,2020,KFOX:2829" majorChannelNo="14" minorChannelNo="1" serviceCategory="1" serviceId="5001" shortServiceName="KFOX" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.14.1" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service serviceCategory="4" serviceId="5002" shortServiceName="ESG" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.14.1" slsDestinationUdpPort="5100" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2020,KDBC:2821" majorChannelNo="4" minorChannelNo="1" serviceCategory="1" serviceId="5003" shortServiceName="KDBC" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.4.1" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service drmSystemID="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" globalServiceID="https://doi.org/10.5239/F1BC-7AFD" majorChannelNo="9" minorChannelNo="1" protected="true" serviceCategory="1" serviceId="5004" shortServiceName="KTSM" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.9.1" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service drmSystemID="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" globalServiceID="https://doi.org/10.5239/F89C-211F" majorChannelNo="48" minorChannelNo="1" protected="true" serviceCategory="1" serviceId="5005" shortServiceName="KTDO" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.48.1" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="https://doi.org/10.5239/7DC5-948D" majorChannelNo="7" minorChannelNo="1" serviceCategory="1" serviceId="5006" shortServiceName="KVIA" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.7.1" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service broadbandAccessRequired="true" configuration="Broadband" globalServiceID="tag:sinclairplatform.com,2020:T2:KFOX" majorChannelNo="14" minorChannelNo="10" serviceCategory="1" serviceId="5007" shortServiceName="T2" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.14.10" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:broadspanwireless.com,2023:2828:KFOX-TV:2829" hidden="true" hideInGuide="true" serviceCategory="3" serviceId="5008" shortServiceName="DDAAS" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.14.100" slsDestinationUdpPort="6000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service broadbandAccessRequired="true" configuration="Broadband" globalServiceID="tag:sinclairplatform.com,2020:PBTV:KFOX" majorChannelNo="14" minorChannelNo="11" serviceCategory="1" serviceId="5009" shortServiceName="PBTV" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.14.11" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service configuration="Broadcast" globalServiceID="tag:sinclairplatform.com,2020:Gameloop:KFOX" majorChannelNo="14" minorChannelNo="20" serviceCategory="3" serviceId="5010" shortServiceName="GMLOOP" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.14.20" slsDestinationUdpPort="5000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2020:Roxi:kfox" majorChannelNo="14" minorChannelNo="21" serviceCategory="3" serviceId="5011" shortServiceName="ROXi" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.14.21" slsDestinationUdpPort="5000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
</SLT>

Service 5001: KFOX (14.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.14.1:5000

Video: 1280x720p (59.94 fps)
Codec: hev1.2.4.L120.B0

Audio: 6 ch @ 96 kbps
Codec: ac-4.02.01.01

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020,KFOX:2829
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.14.1:5000
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5001"><DeliveryMethod><BroadcastAppService><BasePattern>a0-</BasePattern><BasePattern>a1-</BasePattern><BasePattern>d0-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	N/A
200	22	audio	N/A
201	Audio3_3	audio	N/A
300	Data4_4	subtitles	N/A

Raw XML

<?xml version="1.0" encoding="utf-8"?><S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="3500000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="22"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a1-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="Audio3_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d0-$TOI$.mp4s"><fdt:File TOI="1" Content-Location="d0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="Data4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="19"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="56"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="170"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-11-18T05:32:56Z)

Type: dynamic
Min Buffer Time: PT2.002S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 3500000 (3.5 Mbps)
Codecs: hev1.2.4.L120.B0
Resolution: 1280x720 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-init.mp4
- Media URL: video-$Number$.mp4v
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Initialization: a0-init.mp4
- Media URL: a0-$Number$.mp4a
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-init.mp4
- Media URL: a1-$Number$.mp4a
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: Data4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: d0-init.mp4
- Media URL: d0-$Number$.mp4s
- Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<?xml version="1.0" encoding="UTF-8"?><MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2.002S" minimumUpdatePeriod="PT6.006S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-11-18T05:32:56Z" timeShiftBufferDepth="PT12.012S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="720" maxWidth="1280" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="720" minWidth="1280" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="3500000" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_1" sar="1:1" scanType="progressive" width="1280"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0-init.mp4" media="a0-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="22"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <SegmentTemplate duration="480480" initialization="a1-init.mp4" media="a1-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="Audio3_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="480480" initialization="d0-init.mp4" media="d0-$Number$.mp4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data4_4"/></AdaptationSet>   </Period></MPD>

Service 5002: ESG

Protocol: ROUTE
Category: ESG Service

Source: 172.16.200.1
Destination: 239.255.14.1:5100

Hidden: No
App: No

Service Details (from SLT)

Global Service ID:
Category: 4 (ESG Service)
SLS Destination: 239.255.14.1:5100
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5002"></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: 239.255.14.1:5100

TSI	Representation ID	Content Type	Content Ratings
50			N/A
60			N/A
80			N/A

Raw XML

<?xml version="1.0" encoding="utf-8"?><S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS sIpAddr="172.16.200.1" dIpAddr="239.255.14.1" dPort="5100"><LS tsi="50"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="1367" Content-Location="sgdd_1367" Content-Length="56155" Transfer-Length="5894" Content-Type="application/vnd.oma.bcast.sgdd xml" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="60"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="3088" Content-Location="sgdu_content_3088" Content-Length="390541" Transfer-Length="43596" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File><fdt:File TOI="4298" Content-Location="sgdu_service_schedule_4298" Content-Length="77023" Transfer-Length="7130" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="80"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="5777" Content-Location="s28719_ll_h15_ac.png" Content-Length="8623" Transfer-Length="8259" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5778" Content-Location="s28711_ll_h15_ab.png" Content-Length="9791" Transfer-Length="9276" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5779" Content-Location="s28717_h3_aa.png" Content-Length="12435" Transfer-Length="11564" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5780" Content-Location="s73245_ll_h15_ac.png" Content-Length="8530" Transfer-Length="8309" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5781" Content-Location="s28708_ll_h15_ac.png" Content-Length="16622" Transfer-Length="16456" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5782" Content-Location="GNLZZGG002BLPWC.png" Content-Length="10543" Transfer-Length="10051" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="4"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="186"></item></metadataEnvelope>

Electronic Service Guide (ESG) - 6 Service(s), 414 Program(s) (from 426 fragments)

Service : ROXi (14.21)

Field	Value
ID	urn:digicap:svc:5011:1767466370037
Status	tag:sinclairpla
Description	ROXi

Raw XML (0 fragments)

Service : KVIA (7.1)

Field	Value
ID	urn:digicap:svc:5006:1767466370037
Status	https://doi.org
Description	KVIA

Raw XML (0 fragments)

Service : KTDO (48.1)

Field	Value
ID	urn:digicap:svc:5005:1767466370037
Status	https://doi.org
Description	KTDO

Raw XML (0 fragments)

Service : KTSM (9.1)

Field	Value
ID	urn:digicap:svc:5004:1767466370037
Status	https://doi.org
Description	KTSM

Raw XML (0 fragments)

Service : KDBC (4.1)

Field	Value
ID	urn:digicap:svc:5003:1767466370037
Status	tag:sinclairpla
Description	KDBC

Raw XML (0 fragments)

Service : KFOX (14.1)

Field	Value
ID	urn:digicap:svc:5001:1767466370037
Status	tag:sinclairpla
Description	KFOX

Raw XML (0 fragments)

Service 5003: KDBC (4.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.4.1:5000

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 6 ch @ 96 kbps
Codec: ac-4.02.01.01

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020,KDBC:2821
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.4.1:5000
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5003"><DeliveryMethod><BroadcastAppService><BasePattern>a0-</BasePattern><BasePattern>a1-</BasePattern><BasePattern>d0-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	N/A
200	22	audio	N/A
201	Audio3_3	audio	N/A
300	Data4_4	subtitles	N/A

Raw XML

<?xml version="1.0" encoding="utf-8"?><S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="4000000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="22"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a1-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="Audio3_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d0-$TOI$.mp4s"><fdt:File TOI="1" Content-Location="d0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="Data4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="19"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="117"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="207"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-11-18T05:33:02Z)

Type: dynamic
Min Buffer Time: PT2.002S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 4000000 (4.0 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-init.mp4
- Media URL: video-$Number$.mp4v
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Initialization: a0-init.mp4
- Media URL: a0-$Number$.mp4a
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-init.mp4
- Media URL: a1-$Number$.mp4a
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: Data4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: d0-init.mp4
- Media URL: d0-$Number$.mp4s
- Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<?xml version="1.0" encoding="UTF-8"?><MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2.002S" minimumUpdatePeriod="PT6.006S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-11-18T05:33:02Z" timeShiftBufferDepth="PT12.012S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="4000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0-init.mp4" media="a0-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="22"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <SegmentTemplate duration="480480" initialization="a1-init.mp4" media="a1-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="Audio3_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="480480" initialization="d0-init.mp4" media="d0-$Number$.mp4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data4_4"/></AdaptationSet>   </Period></MPD>

Service 5004: KTSM (9.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.9.1:5000

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 6 ch @ 96 kbps
Codec: ac-4.02.01.01

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: https://doi.org/10.5239/F1BC-7AFD
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.9.1:5000
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)
Protected: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5004"><DeliveryMethod><BroadcastAppService><BasePattern>a0-</BasePattern><BasePattern>a1-</BasePattern><BasePattern>d0-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	N/A
200	22	audio	N/A
201	Audio3_3	audio	N/A
300	Data4_4	subtitles	N/A

Raw XML

<?xml version="1.0" encoding="utf-8"?><S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="4000000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="22"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a1-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="Audio3_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d0-$TOI$.mp4s"><fdt:File TOI="1" Content-Location="d0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="Data4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="19"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="92"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="70"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-12-29T03:19:27Z)

Type: dynamic
Min Buffer Time: PT2.002S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 4000000 (4.0 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-init.mp4
- Media URL: video-$Number$.mp4v
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ktsm_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Initialization: a0-init.mp4
- Media URL: a0-$Number$.mp4a
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ktsm_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-init.mp4
- Media URL: a1-$Number$.mp4a
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ktsm_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: Data4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: d0-init.mp4
- Media URL: d0-$Number$.mp4s
- Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<?xml version="1.0" encoding="UTF-8"?><MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2.002S" minimumUpdatePeriod="PT6.006S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-12-29T03:19:27Z" timeShiftBufferDepth="PT12.012S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="bcfc225d-bf8d-5bf0-9c0a-fc906bdd6854" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="bcfc225d-bf8d-5bf0-9c0a-fc906bdd6854" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ktsm_g2_p2_1</dashif:Laurl>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="4000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="bcfc225d-bf8d-5bf0-9c0a-fc906bdd6854" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="bcfc225d-bf8d-5bf0-9c0a-fc906bdd6854" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ktsm_g2_p2_1</dashif:Laurl>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0-init.mp4" media="a0-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="22"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="bcfc225d-bf8d-5bf0-9c0a-fc906bdd6854" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="bcfc225d-bf8d-5bf0-9c0a-fc906bdd6854" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ktsm_g2_p2_1</dashif:Laurl>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>         </ContentProtection>         <SegmentTemplate duration="480480" initialization="a1-init.mp4" media="a1-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="Audio3_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="480480" initialization="d0-init.mp4" media="d0-$Number$.mp4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data4_4"/></AdaptationSet>   </Period></MPD>

Service 5005: KTDO (48.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.48.1:5000

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 6 ch @ 96 kbps
Codec: ac-4.02.01.01

Hidden: No
App: Run3TV

Service Details (from SLT)

Global Service ID: https://doi.org/10.5239/F89C-211F
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.48.1:5000
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)
Protected: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5005"><DeliveryMethod><BroadcastAppService><BasePattern>a0-</BasePattern><BasePattern>a1-</BasePattern><BasePattern>d0-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	N/A
200	22	audio	N/A
201	Audio3_3	audio	N/A
300	Data4_4	subtitles	N/A

Raw XML

<?xml version="1.0" encoding="utf-8"?><S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="4000000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="22"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a1-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="Audio3_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d0-$TOI$.mp4s"><fdt:File TOI="1" Content-Location="d0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="Data4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="19"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="65"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="61"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="1"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-11-18T05:33:02Z)

Type: dynamic
Min Buffer Time: PT2.002S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 4000000 (4.0 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-init.mp4
- Media URL: video-$Number$.mp4v
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ktdo_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Initialization: a0-init.mp4
- Media URL: a0-$Number$.mp4a
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ktdo_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-init.mp4
- Media URL: a1-$Number$.mp4a
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ktdo_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: Data4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: d0-init.mp4
- Media URL: d0-$Number$.mp4s
- Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<?xml version="1.0" encoding="UTF-8"?><MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2.002S" minimumUpdatePeriod="PT6.006S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-11-18T05:33:02Z" timeShiftBufferDepth="PT12.012S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="40c15e40-ee2d-56db-83f9-11ddb856f337" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="40c15e40-ee2d-56db-83f9-11ddb856f337" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>AAAASnBzc2gAAAAA7e+LqXnWSs6jyCfc1R0h7QAAACoiDGt0ZG9fZzJfcDJfMUjj3JWbBmoUYXRzY19ncm91cDJfcHJvZmlsZTIAAAJocHNzaAAAAADt74upedZKzqPIJ9zVHSHtAAACSCIMa3Rkb19nMl9wMl8xSOPclZsGWAJqFGF0c2NfZ3JvdXAyX3Byb2ZpbGUyclgKEOZJn+O10FpLj0aegfdqNP0SEEDBXkDuLVbbg/kR3bhW8zcaIEj3+5X7F/UpD2GHFa1OpkNSwQspdHYnVNRKxK33tb3jIhDtjyMzm0Y1Zz/D1M12cIcuclgKEMtonnMvM1NbiAzYoZigpGUSEEDBXkDuLVbbg/kR3bhW8zcaIFzGhD7MG6XeSd4jfFC3ZztCOP31g0yx6S+BddktnBvkIhDsX96LdsjcuNCOzIqVA2O3clgKEBRmMmb4tl/PnUewUYQHONMSEHWYOcgDZlPYn1Vm5Swe9N0aIMvuPGWmKViDKcALeLukiWc0XppSx7w3Kj0gExjxJuc4IhCOCxY2fbQwWCG0hWMjlkACclgKEAqxnRcP+VBvjQwDq2QUA5QSEHWYOcgDZlPYn1Vm5Swe9N0aID0rfWXGWyGXyhb7QyYwvkG8XwLXS+rRsOvQbEwCe4T/IhBngK+G4gehh6dtBV464zkVclgKEH5/pHjRklnHu9YlM8IBQJYSEJuu27+Qp1NitLuvVOk/iTIaIMwKsH2Z2clGH9eYzcd+sej3e5G86PgLJMpexQJtZYNwIhBvFYCwms3JDcWeQ0tsuLJ9clgKEHg5LB43JVKIjuApVhHyY3wSEJuu27+Qp1NitLuvVOk/iTIaIMJ9mHekpGh/0Gs5PsLTxwapltxVgsC5iwsMGbmOIj6KIhBxdjMf04aFLnhzg7JELTdu</cenc:pssh>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ktdo_g2_p2_1</dashif:Laurl>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="4000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="40c15e40-ee2d-56db-83f9-11ddb856f337" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="40c15e40-ee2d-56db-83f9-11ddb856f337" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ktdo_g2_p2_1</dashif:Laurl>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0-init.mp4" media="a0-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="22"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="40c15e40-ee2d-56db-83f9-11ddb856f337" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="40c15e40-ee2d-56db-83f9-11ddb856f337" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ktdo_g2_p2_1</dashif:Laurl>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>         </ContentProtection>         <SegmentTemplate duration="480480" initialization="a1-init.mp4" media="a1-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="Audio3_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="480480" initialization="d0-init.mp4" media="d0-$Number$.mp4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data4_4"/></AdaptationSet>   </Period></MPD>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://atsc-ba-prod.nextgentv.nbcuni.com/run3tv-common/index.html

Raw XML

<?xml version="1.0" encoding="UTF-8"?><HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage appContextId="tv:atsc3-app.ktdo.nbcuni.com"
    bbandEntryPageUrl="https://atsc-ba-prod.nextgentv.nbcuni.com/run3tv-common/index.html">
</HTMLEntryPackage>
</HELD>

Service 5006: KVIA (7.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.7.1:5000

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 6 ch @ 96 kbps
Codec: ac-4.02.01.01

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: https://doi.org/10.5239/7DC5-948D
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.7.1:5000
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5006"><DeliveryMethod><BroadcastAppService><BasePattern>a0-</BasePattern><BasePattern>a1-</BasePattern><BasePattern>d0-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	N/A
200	22	audio	N/A
201	Audio3_3	audio	N/A
300	Data4_4	subtitles	N/A

Raw XML

<?xml version="1.0" encoding="utf-8"?><S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="4000000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="22"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a1-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="Audio3_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d0-$TOI$.mp4s"><fdt:File TOI="1" Content-Location="d0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="Data4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="19"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="38"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="4"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-11-18T05:33:02Z)

Type: dynamic
Min Buffer Time: PT2.002S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 4000000 (4.0 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-init.mp4
- Media URL: video-$Number$.mp4v
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Initialization: a0-init.mp4
- Media URL: a0-$Number$.mp4a
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-init.mp4
- Media URL: a1-$Number$.mp4a
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: Data4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: d0-init.mp4
- Media URL: d0-$Number$.mp4s
- Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<?xml version="1.0" encoding="UTF-8"?><MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2.002S" minimumUpdatePeriod="PT6.006S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-11-18T05:33:02Z" timeShiftBufferDepth="PT12.012S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="4000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0-init.mp4" media="a0-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="22"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <SegmentTemplate duration="480480" initialization="a1-init.mp4" media="a1-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="Audio3_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="480480" initialization="d0-init.mp4" media="d0-$Number$.mp4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data4_4"/></AdaptationSet>   </Period></MPD>

Service 5007: T2 (14.10)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.14.10:5000

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 16 ch @ 448 kbps
Codec: ac-4.02.01.02

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:T2:KFOX
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.14.10:5000
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)
Broadband Required: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5007"><DeliveryMethod><UnicastAppService><BasePattern>a0-22-</BasePattern><BasePattern>d0-Data3_3-</BasePattern><BasePattern>video-Video1_1-</BasePattern></UnicastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="93"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="193"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2026-01-03T20:05:03Z)

Type: dynamic
Min Buffer Time: PT10.01S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 7000000 (7.0 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=424192954305120, d=480480, r=29

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Bandwidth: 448000 (448 kbps)
Codecs: ac-4.02.01.02
Audio Sample Rate: 48000 Hz
Audio Channels: 16
Segment Template:
- Timescale: 240000
- S: t=424192954305120, d=480480, r=29

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: Data3_3

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Timescale: 240000
- S: t=424192954305120, d=480480, r=29

Raw XML

<?xml version="1.0" encoding="UTF-8"?><MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT10.01S" minimumUpdatePeriod="PT30.03S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2026-01-03T20:05:03Z" timeShiftBufferDepth="PT1M0.06S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <BaseURL>https://kfox-sbgtv.atsc.stream/t2/</BaseURL><AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="video-$RepresentationID$-init.mp4v" media="video-$RepresentationID$-$Time$.mp4v" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="424192954305120"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="7000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="a0-$RepresentationID$-init.mp4a" media="a0-$RepresentationID$-$Time$.mp4a" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="424192954305120"/>            </SegmentTimeline>         </SegmentTemplate>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="16"/>               <Representation audioSamplingRate="48000" bandwidth="448000" codecs="ac-4.02.01.02" id="22"/></AdaptationSet><AdaptationSet contentType="text" id="2" lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate initialization="d0-$RepresentationID$-init.mp4s" media="d0-$RepresentationID$-$Time$.mp4s" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="424192954305120"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data3_3"/></AdaptationSet>   </Period></MPD>

Service 5008: DDAAS

Protocol: ROUTE
Category: App-Based Service

Source: 172.16.200.1
Destination: 239.255.14.100:6000

Hidden: Service & Guide
App: No

Service Details (from SLT)

Global Service ID: tag:broadspanwireless.com,2023:2828:KFOX-TV:2829
Category: 3 (App-Based Service)
SLS Destination: 239.255.14.100:6000
SLS Source: 172.16.200.1
SLS Protocol Version: . (ROUTE)
Hidden: Yes
Hide in Guide: Yes

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"></metadataEnvelope>

Service 5009: PBTV (14.11)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.14.11:5000

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 16 ch @ 448 kbps
Codec: ac-4.02.01.02

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:PBTV:KFOX
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.14.11:5000
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)
Broadband Required: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5009"><DeliveryMethod><UnicastAppService><BasePattern>a0-24-</BasePattern><BasePattern>d0-Data3_5-</BasePattern><BasePattern>video-Video1_1-</BasePattern><BasePattern>video-Video1_2-</BasePattern><BasePattern>video-Video1_3-</BasePattern></UnicastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="66"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="223"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2026-01-03T20:05:31Z)

Type: dynamic
Min Buffer Time: PT10.01S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_3

Bandwidth: 1000000 (1000 kbps)
Codecs: hev1.2.4.L93.B0
Resolution: 960x540 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=424192961031840, d=480480, r=29

Representation ID: Video1_2

Bandwidth: 4000000 (4.0 Mbps)
Codecs: hev1.2.4.L120.B0
Resolution: 1280x720 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=424192961031840, d=480480, r=29

Representation ID: Video1_1

Bandwidth: 8000000 (8.0 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=424192961031840, d=480480, r=29

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 24

Bandwidth: 448000 (448 kbps)
Codecs: ac-4.02.01.02
Audio Sample Rate: 48000 Hz
Audio Channels: 16
Segment Template:
- Timescale: 240000
- S: t=424192961031840, d=480480, r=29

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: Data3_5

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Timescale: 240000
- S: t=424192961031840, d=480480, r=29

Raw XML

<?xml version="1.0" encoding="UTF-8"?><MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT10.01S" minimumUpdatePeriod="PT30.03S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2026-01-03T20:05:31Z" timeShiftBufferDepth="PT1M0.06S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <BaseURL>https://kfox-sbgtv.atsc.stream/pickleball/</BaseURL><AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="540" minWidth="960" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="video-$RepresentationID$-init.mp4v" media="video-$RepresentationID$-$Time$.mp4v" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="424192961031840"/>            </SegmentTimeline>         </SegmentTemplate>                                 <Representation bandwidth="1000000" codecs="hev1.2.4.L93.B0" frameRate="60000/1001" height="540" id="Video1_3" sar="1:1" scanType="progressive" width="960"/><Representation bandwidth="4000000" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_2" sar="1:1" scanType="progressive" width="1280"/><Representation bandwidth="8000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="a0-$RepresentationID$-init.mp4a" media="a0-$RepresentationID$-$Time$.mp4a" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="424192961031840"/>            </SegmentTimeline>         </SegmentTemplate>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="16"/>               <Representation audioSamplingRate="48000" bandwidth="448000" codecs="ac-4.02.01.02" id="24"/></AdaptationSet><AdaptationSet contentType="text" id="2" lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate initialization="d0-$RepresentationID$-init.mp4s" media="d0-$RepresentationID$-$Time$.mp4s" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="424192961031840"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data3_5"/></AdaptationSet>   </Period></MPD>

Service 5010: GMLOOP (14.20)

Protocol: ROUTE
Category: App-Based Service

Source: 172.16.200.1
Destination: 239.255.14.20:5000

Hidden: No
App: GameLoop

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:Gameloop:KFOX
Category: 3 (App-Based Service)
SLS Destination: 239.255.14.20:5000
SLS Source: 172.16.200.1
SLS Protocol Version: . (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5010"></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="1"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="2"></item></metadataEnvelope>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://nextgen.gameloop.tv/run3tv-common/index.html

Raw XML

<?xml version="1.0" encoding="UTF-8"?><HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage appContextId="tag:sinclairplatform.com,2020:Gameloop:KFOX" bbandEntryPageUrl="https://nextgen.gameloop.tv/run3tv-common/index.html"></HTMLEntryPackage>
</HELD>

Service 5011: ROXi (14.21)

Protocol: ROUTE
Category: App-Based Service

Source: 172.16.200.1
Destination: 239.255.14.21:5000

Hidden: No
App: ROXi

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:Roxi:kfox
Category: 3 (App-Based Service)
SLS Destination: 239.255.14.21:5000
SLS Source: 172.16.200.1
SLS Protocol Version: . (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5011"></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="1"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="4"></item></metadataEnvelope>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://cdn.prod.tvapp.roxi.tv/releases/prod-atsc/index.html#/atsc,faststream,showId=46eb1cf29052,prod

Raw XML

<?xml version="1.0" encoding="UTF-8"?><HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage bbandEntryPageUrl="https://cdn.prod.tvapp.roxi.tv/releases/prod-atsc/index.html#/atsc,faststream,showId=46eb1cf29052,prod" appContextId="tag:sinclairplatform.com,2020:Roxi:kfox" />
</HELD>

Other Global LLS Tables

System Time Details - Actual Timestamp in L1Detail

Attribute	Value
currentUtcOffset	37
utcLocalOffset	-PT7H
dsStatus	false

Raw XML

<?xml version="1.0" encoding="utf-8"?>
<SystemTime xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/ SYSTIME-1.0-20211208.xsd" currentUtcOffset="37" utcLocalOffset="-PT7H" dsStatus="false"/>

Input Info

Attribute	Value
Input Type	ALP-PCAP File
File Name	33716-0-20260103-150540-p0p1-alp.pcap
Total Packets Processed	118840
File Last Modified	2026-01-03 23:43:45 EST
Analysis Run Time	2026-01-04 05:40:23 EST

ATSC 3.0 Data Usage Analysis

IP:Port (ID)	Usage ↓	Service	Type	Total Data	Bitrate
239.255.9.1:5000 (TSI 100)	18.43%	KTSM	Video	15.70 MB	4.19 Mbps
239.255.48.1:5000 (TSI 100)	18.33%	KTDO	Video	15.62 MB	4.17 Mbps
239.255.7.1:5000 (TSI 100)	18.29%	KVIA	Video	15.59 MB	4.16 Mbps
239.255.4.1:5000 (TSI 100)	18.22%	KDBC	Video	15.53 MB	4.14 Mbps
239.255.14.1:5000 (TSI 100)	15.98%	KFOX	Video	13.62 MB	3.64 Mbps
224.0.23.60:4937 (LLS)	1.26%	LLS Signaling	LLS Signaling	1.07 MB	286.0 Kbps
239.255.48.1:5000 (TSI 0)	1.03%	KTDO	Service Signaling	878.0 KB	234.4 Kbps
239.255.9.1:5000 (TSI 0)	0.98%	KTSM	Service Signaling	835.4 KB	223.0 Kbps
239.255.4.1:5000 (TSI 0)	0.63%	KDBC	Service Signaling	537.3 KB	143.4 Kbps
239.255.7.1:5000 (TSI 0)	0.63%	KVIA	Service Signaling	537.1 KB	143.4 Kbps
239.255.14.1:5000 (TSI 0)	0.63%	KFOX	Service Signaling	537.0 KB	143.3 Kbps
239.255.9.1:5000 (TSI 200)	0.49%	KTSM	Audio	417.2 KB	111.3 Kbps
239.255.48.1:5000 (TSI 200)	0.49%	KTDO	Audio	417.1 KB	111.3 Kbps
239.255.4.1:5000 (TSI 200)	0.47%	KDBC	Audio	398.3 KB	106.3 Kbps
239.255.7.1:5000 (TSI 200)	0.47%	KVIA	Audio	398.2 KB	106.3 Kbps
239.255.14.1:5000 (TSI 200)	0.47%	KFOX	Audio	398.1 KB	106.3 Kbps
239.255.14.1:5100 (TSI 0)	0.41%	ESG	Service Signaling	346.9 KB	92.6 Kbps
239.255.48.1:5000 (TSI 201)	0.27%	KTDO	Audio	230.4 KB	61.5 Kbps
239.255.9.1:5000 (TSI 201)	0.27%	KTSM	Audio	230.4 KB	61.5 Kbps
239.255.14.11:5000 (TSI 0)	0.26%	PBTV	Service Signaling	223.6 KB	59.7 Kbps
239.255.4.1:5000 (TSI 201)	0.25%	KDBC	Audio	211.9 KB	56.6 Kbps
239.255.14.1:5000 (TSI 201)	0.25%	KFOX	Audio	211.9 KB	56.6 Kbps
239.255.7.1:5000 (TSI 201)	0.25%	KVIA	Audio	211.7 KB	56.5 Kbps
239.255.14.10:5000 (TSI 0)	0.23%	T2	Service Signaling	194.8 KB	52.0 Kbps
239.255.14.1:5100 (TSI 80)	0.22%	ESG	ROUTE Media	186.4 KB	49.8 Kbps
239.255.14.21:5000 (TSI 0)	0.12%	ROXi	Service Signaling	104.0 KB	27.8 Kbps
239.255.14.20:5000 (TSI 0)	0.12%	GMLOOP	Service Signaling	101.1 KB	27.0 Kbps
239.255.14.1:5100 (TSI 50)	0.09%	ESG	ROUTE Media	74.0 KB	19.7 Kbps
239.255.14.1:5100 (TSI 60)	0.09%	ESG	ROUTE Media	73.4 KB	19.6 Kbps
239.255.7.1:5000 (TSI 300)	0.08%	KVIA	Captions	71.9 KB	19.2 Kbps
239.255.14.1:5000 (TSI 300)	0.08%	KFOX	Captions	70.2 KB	18.7 Kbps
239.255.9.1:5000 (TSI 300)	0.08%	KTSM	Captions	67.6 KB	18.1 Kbps
239.255.48.1:5000 (TSI 300)	0.07%	KTDO	Captions	58.8 KB	15.7 Kbps
239.255.14.100:6000 (TSI 0)	0.06%	DDAAS	Service Signaling	48.9 KB	13.1 Kbps
239.255.4.1:5000 (TSI 300)	0.02%	KDBC	Captions	20.8 KB	5.5 Kbps

Total: 85.22 MB | Signaling: 6.36% | Media: 93.64% | Other: 0.00%

RENDER - RabbitEars NextGen Data Evaluator Report - v0.2.1

Physical Layer Pipes - 2 PLPs (L1 BSID: Not Set)

Service Summary (SLT BSID: 2828)

Certificate Details

Service 5001: KFOX (14.1)

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: Data4_4

Raw XML

Service 5002: ESG

Raw XML

ROUTE Stream: 239.255.14.1:5100

Raw XML

Raw XML

Service 5003: KDBC (4.1)

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: Data4_4

Raw XML

Service 5004: KTSM (9.1) Encrypted

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: Data4_4

Raw XML

Service 5005: KTDO (48.1) Encrypted

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: Data4_4

Raw XML

Raw XML

Service 5006: KVIA (7.1)

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: Data4_4

Raw XML

Service 5004: KTSM (9.1)

Service 5005: KTDO (48.1)

Service 5007: T2 (14.10)

Service 5008: DDAAS

Service 5009: PBTV (14.11)
